This 2.5-ton diesel micro-hauler redefines compact utility with its impressive payload capacity and Euro V compliant diesel efficiency. Designed for businesses that need serious hauling power in tight spaces, our mini-diesel workhorse delivers where larger trucks can’t go while meeting strict environmental standards.
Parameters
| Model | BJ5040V8JA6 |
| Outside Dimension | 5620×1900×2675 |
| Cargo Body Dimension | 3700×1750×1750 |
| Wheel Base | 3100 |
| Cabin Type | T5,1620mm, Single |
| Chassis Width | 84/132 |
| Curb Weight | 2000 |
| Load Capacity | 2500 |
| Total Weight | 4500 |
| Engine | Vertical,In-line,Four-stroke,Water-cool,Common rail,SCR |
| Engine Model | D19TCIE3 |
| Fuel type | Diesel |
| Max. Power(kw/r.p.m) | 85kw |
| Displacement (cc) | 1900 |
| Emission standard | Euro V |
| Gear position | 135/24R |
| Front axle | Steel Tube Welded type |
| Rear axle | Unitary Pipa type |
| Differential Ratio | 4.33 |
| Driving brake | Hydraulic double-pipeline, Front Disc/Rear Drum |
| Parking brake | Drum middle brake |
| Leaf Spring Quantity | 3+Shock absorber |
| Leaf Spring Quantity | 3+3+Shock absorber |
| Tires | 185R158PR*7 |
• D19TCIE3 common rail engine produces 85kW with exceptional torque
• SCR system ensures clean diesel compliance with Euro V regulations
• 1900cc displacement optimized for fuel efficiency and durability
• Compact diesel powerplant designed for 10,000+ hour service life
• 5620mm overall length fits urban loading zones
• 3700×1750mm cargo area maximizes usable space
• 2675mm height clears most parking structures
• Micro-hauler chassis provides 2500kg payload in compact form
• Reinforced steel tube welded frame
• 3+3+2 leaf spring suspension for mixed loads
• 165R15 commercial-grade tires
• Hydraulic disc/drum brake system
Dump body conversion ready
Underbody protection plates
Toolbox mounting points
High-intensity work lights
Slip-resistant cargo floor
Partitioned load areas
Liftgate preparation
Interior lighting package
12V/24V power outlets
Lockable storage compartments
Fold-down work tables
Roof rack provisions
| Feature | Professional Advantage |
|---|---|
| Euro V diesel | Future-proof compliance |
| 2500kg capacity | Full commercial payload |
| 3100mm wheelbase | Stable loaded handling |
| Common rail tech | Fuel-efficient operation |
• 30% better fuel economy than older diesel models
• 92% first-pass emissions compliance rate
• 50,000km service intervals
• 3-year drivetrain warranty
✓ True 2.5-ton capability in compact dimensions
✓ Modern clean diesel without urea hassles
✓ Commercial-grade durability for daily use
✓ Low total cost of ownership
This diesel micro-hauler proves you don’t need massive size to get serious work done. From urban deliveries to trade services, this compact diesel performer handles demanding jobs with surprising capability.
For a demonstration of how this mini work truck can transform your operations, contact our commercial vehicle specialists today.
