This 2.5-ton mini-truck represents the next evolution in compact urban transport solutions. Powered by a Euro V compliant gasoline engine, our city delivery specialist combines maneuverability with surprising payload capacity, making it ideal for navigating crowded metropolitan areas while meeting strict emission regulations.
Parameters
| Model | BJ5030V5JV5 |
| Outside Dimension | 5220×1850×2625 |
| Cargo Body Dimension | 3300×1710×1700 |
| Wheel Base | 2850 |
| Cabin Type | T5,1620mm, Single |
| Chassis Width | 82/130/82 |
| Curb Weight | 1000 |
| Load Capacity | 2500 |
| Total Weight | 3500 |
| Engine | Vertical, In-line, Four-stroke, Water-cool, Electronically controlled gasoline injection sequence |
| Engine Model | DAM15L |
| Fuel type | Gasoline |
| Max. Power(kw/r.p.m) | 82kw |
| Displacement (cc) | 1500 |
| Emission standard | Euro V |
| Gear position | 135/24R |
| Front axle | Steel Tube Welded type |
| Rear axle | Unitary Pipa type |
| Differential Ratio | 4.33 |
| Driving brake | Hydraulic double-pipeline, Front Disc/Rear Drum |
| Parking brake | Drum middle brake |
| Leaf Spring Quantity | 3+Shock absorber |
| Leaf Spring Quantity | 5+2+Shock absorber |
| Tires | 185R14*7 |
• DAM15L 1.5L engine delivers 82kW with exceptional fuel economy
• Advanced electronic fuel injection ensures Euro V emission compliance
• 4.33 final drive ratio optimized for stop-and-go city driving
• Compact gasoline hauler design reduces maintenance complexity
• 5220mm total length fits standard parking spaces
• Tight 10.7m turning circle for alleyway access
• Low 2625mm height clears urban height restrictions
• 3300×1710mm cargo area maximizes load volume in minimal footprint
• Front disc/rear drum brakes for reliable urban stopping
• 3+5+2 leaf spring configuration absorbs pothole impacts
• 185R14 tires balance load capacity and ride comfort
• T5 single cab provides essential workspace without bulk
Low-loading-height modification
Cargo area partition options
Non-slip flooring surface
Side access steps
Tool storage compartments
Auxiliary power outlets
Work surface extensions
Weatherproof cargo cover
Fold-down side panels
Integrated awning mounts
Refrigeration unit prep
Easy-clean interior surfaces
| Feature | Urban Advantage |
|---|---|
| Euro V gasoline | Low-emission city access |
| 2500kg payload | Surprising small truck capacity |
| 2850mm wheelbase | Agile urban maneuverability |
| Hydraulic brakes | Reliable traffic-density stopping |
• 28% more fuel efficient than comparable diesel models
• 95% first-time pass rate on urban emissions tests
• 50% lower maintenance costs than competitors
• 3-year/100,000km powertrain warranty
✓ Compact dimensions with full 2.5-ton capability
✓ Gasoline convenience without diesel restrictions
✓ Low operating costs for urban delivery fleets
✓ Future-proof compliance with Euro V standards
This urban mini-hauler proves that big capability can come in small packages. Whether you’re delivering packages, stocking urban storefronts, or operating mobile services, this 2.5-ton gasoline workhorse delivers where larger trucks can’t go.
For a demonstration of how this compact city truck can optimize your urban operations, contact our micro-mobility specialists today
