Protective Design Off-Road Vehicle

Core Selling Points

Powerful Engine Performance

The Protective Design Off-Road Vehicle engine is a standout. Its single – cylinder, 4 – stroke design with 4 valves and liquid – cooling allows for efficient power delivery. Whether you’re navigating rough terrains or need to carry heavy loads, the 29Kw max power and 44N.m max torque ensure smooth and strong performance. The engine’s structure also contributes to better fuel combustion, balancing power and efficiency.

Versatile Drive and Suspension

Equipped with a 2WD/4WD system and front differential lock, the U570 – 2 adapts to various terrains. The double A – arm independent suspension, along with coil spring + oil damping shock absorbers, provides a comfortable ride even on bumpy roads. Four – wheel hydraulic disc brakes ensure reliable stopping power, enhancing safety during rides.

Practical Design for Multiple Uses

With a gross weight of 425kgs and front/rear rack capacities (F: 20kg / 44lbs; R: 40kg / 88lbs), it’s built for utility. The ATV 25×8 – 12 front tires and 25×10 – 12 rear tires offer excellent traction. A max speed of 85 km/h makes it suitable for both work and recreational use, while the CVT transmission ensures easy operation.

Application Scenarios

Outdoor Adventure
For adventure seekers, the Protective Design Off-Road Vehicle is ideal for exploring off – road trails. Its powerful engine and versatile drive system let riders conquer mountains, forests, and deserts. The suspension and tire setup ensure a smooth ride even on the most challenging terrains, providing an exciting and safe adventure experience.
Agricultural and Ranch Work
In rural areas, this ATV serves as a reliable workhorse. Farmers can use it to transport supplies, navigate through fields, and manage livestock. The rack capacities allow for carrying tools, feed, or small harvests, and the 2WD/4WD system helps in traversing muddy or uneven farmland.
Tourism Operations
Tour companies can utilize the Protective Design Off-Road Vehicle for off – road tours. Its ability to carry passengers comfortably (with a design suitable for two riders) and handle different terrains makes it perfect for showing tourists scenic landscapes. Whether it’s a mountainous tour or a desert expedition, this ATV adds an adventurous element to tourism offerings.

FAQ

Q1: What type of fuel does the Protective Design Off-Road Vehicle use?

A: The Protective Design Off-Road Vehicle uses regular gasoline, which is widely available. Its engine is optimized to work efficiently with standard fuel types, ensuring easy refueling during your adventures or work tasks.

Q2: How often should the engine be maintained?

A: Routine engine maintenance is recommended every 50 – 100 hours of use, depending on operating conditions. This includes checking oil levels, inspecting the cooling system, and cleaning or replacing air filters to keep the engine running at its best.

Q3: Can the Protective Design Off-Road Vehicle be used in extreme weather conditions?

A: Yes, the liquid – cooled engine and sealed components allow it to operate in various weather conditions. However, in extremely harsh conditions like deep snow or floods, it’s best to use caution and avoid situations that could damage the vehicle.

Q4: What is the loading capacity of the Protective Design Off-Road Vehicle ?

A: The Protective Design Off-Road Vehicle has a gross weight of 425kgs. The front rack can carry up to 20kg (44lbs) and the rear rack up to 40kg (88lbs), making it suitable for carrying tools, supplies, or small payloads during work or recreational activities.

Model	Protective Design Off-Road Vehicle
Engine Type	Single-cylinder , 4-stroke , 4 valves
Cooling	liquid-cooled
Bore x Stroke (mm/in)	92×75 / 3.62×2.95
Max Power/rpm	29Kw(6750±500r/min)
Horse power	39.4HP
Max Torque	44N.m(6000±500r/min)
Transmission	CVT/ L—H—N—R—P
Max Speed	85 km/h
Drive System	2WD/4WD/Front differential lock
Front /Rear Suspension	Double A-arm independent suspension
Front/Rear Shock Absorber	Coil spring + oil damping
Front/Rear Brakes	Four wheel hydraulic discs Rear wheel parking
Suspension Travel (mm/in)	F: 166/6.54 R:172/6.77
Front Tires	ATV 25 ×8- 12
Rear Tires	ATV 25 ×10- 12
Rim	Front：126 Rear 128
Length x Width x Height (mm/in)	220011801270/86.646.550
Gross Weight	425kgs
Front/Rear Rack Capacity	F: 20kg / 44lbs R:40kg / 88lbs
Package size(mm)	2270×1150×843
Loading Quantity(Pcs)	20FCL : 10PCS 40HQ : 30PCS
