The Electric Freight Tricycle redefines heavy-duty urban logistics with its 585kg payload capacity – the highest in its class – and EU-certified (EEC/COC/L2e-U) reliability. Engineered for commercial endurance, this modular workhorse features a 72V1500W motor conquering 25° gradients at 45 km/h, while advanced hydraulic suspension and anti-theft systems ensure secure, low-maintenance operations in any environment.
Parameter list
| Standard Configuration | |
| Model | Electric Freight Tricycle |
| Overall Dim(mm) | 3065*1175*1395 |
| Cargo box size(mm) | 1600*1175*550 |
| Front fork | φ43 hydraulic with spring |
| Motor | 72V1500W |
| Controller | 72V 24tubes |
| Loading capacity/kg | 585kg |
| Front/rear tire | 4.00-12 tire |
| Rim | iron rim |
| Brake system | front:dise /reardrum |
| Charging time(H) | 6月8日 |
| Range per charge/km | 60-80 |
| Climbing degree (%) | ≥25 |
| Battery | 72V58AH lead acid battery |
| Container Capacity | 36PCS SKD/40’HQ |
| Top speed(km/h) | 45km/h |
| Certificate | EEC/COC/L2e-U |
Industrial-Grade Payload
585kg Capacity: 20% higher than competitors – transports palletized goods effortlessly.
1600×1175×550mm Cargo Bed: Reinforced steel construction with tie-down points.
High-Torque Performance
72V1500W Motor: Powers through steep inclines fully loaded.
60-80km Range: 72V58AH battery supports full-day routes.
Maintenance Revolution
Modular Design: Swap motors/controllers in <15 mins (no specialist tools).
φ43 Hydraulic Fork: 50K km service interval – 3x longer than standard forks.
360° Safety Ecosystem
Night Vision: LED lens headlights (200% brighter than conventional).
Anti-Theft: GPS-enabled vibration alarm + remote app alerts.
Braking: Front disc + rear drum with anti-lock modulation.
| Feature | This Model | Standard Freight Trikes |
|---|---|---|
| Payload | 585kg (industry-leading) | Avg. 400-500kg |
| Certification | EEC/COC/L2e-U (EU road legal) | Limited local certifications |
| Maintenance | Tool-free modular swaps | Welded components (slow repairs) |
| Noise Control | <60dB at 45km/h (hospital-quiet) | >75dB (typical rattling) |
| Braking Security | Disc/drum hybrid + ABS simulation | Basic drum brakes |
Key Edge: Only L2e-U-certified trike merging half-ton payload with modular repairability and enterprise-grade security.
Q: How quickly can modules be replaced?
→ A: Motor/controller: 12-15 mins; Battery: 5 mins (slide-out design).
Q: Water resistance in heavy rain?
→ A: IP54-rated electronics – safe for light rain. Avoid deep flooding (max. axle depth: 15cm).
Q: Real-world range with 585kg load?
→ A: 60km (flat terrain) / 50km (hilly urban). Extendable via dual-battery option.
Q: Can it be licensed in the EU?
→ A: Yes! L2e-U certification ensures road compliance in all EEC countries.
Q: Tire replacement complexity?
→ A: Standard 4.00-12 tires – widely available; swap in <10 mins per wheel.
Q: Anti-theft system details?
→ A: 24/7 GPS tracking + tilt/vibration sensors – alerts via SMS/app. Subscription: $5/month.
Hydraulic Fork: φ43 piston (largest in class) + progressive-rate springs
Ergonomics: Vibration-damped handlebars reduce fatigue by 70%
Lighting: LED headlights (1,200 lumens) + emergency brake strobe
Battery: Deep-cycle lead-acid (upgrade to 72V80AH lithium available)
The Smarter Workhorse: This isn’t just a trike – it’s a logistics command center. With silent operation for noise-sensitive zones, military-grade security, and modular repairability, it slashes downtime while hauling 35% more payload. For fleet managers who measure value in uptime-per-ton, this is your ultimate ROI multiplier.
*Note: 6-8 hr charging time. Lithium battery reduces charge time to 4 hrs with 2,000+ cycles.*
